Portable Indentation Tester (PMT-1000) Product Introduction

Product Overview

The PMT-1000 Portable In-situ Micro-indentation Tester, jointly developed by Wuxi Zhanghua Pharmaceutical Equipment Co., Ltd. and Jova Glenn Technology Co., Ltd.,  is a non-destructive online testing device based on the indentation method/indentation energy difference method. It focuses on mechanical properties and residual stress testing for energy equipment (e.g., pressure vessels, pipelines), serving third-party testing institutions and frontline production units. It provides critical data support for finite element simulation, failure analysis, lifespan evaluation, and safety assessments.


Core Functions

1. Mechanical Property Testing

   - Tensile properties (yield strength, tensile strength)

   - Hardness, fracture toughness, strain hardening index

   - Biaxial residual stress

2. Residual Stress Testing

   - Indentation energy difference method, indentation strain method, X-ray diffraction method (for comparative validation)

3. Application Scenarios

   - Pressure vessels, long-distance pipelines, remanufactured energy equipment

   - Welded joints, thick-walled cylinder weld seams, heat exchanger tube plates, etc.



Technical Advantages

Micro-indentation Technology

Traditional Methods

Non-destructive

Requires sample cutting

Portable & efficient

Laboratory-dependent

Multi-parameter output

Single-parameter testing

Cost-effective

High preparation costs

Supports online testing

Offline operation



Industry Standards & Certifications

- National Standards: GB/T 39535-2020, GB/T 21933-2019

- International Standards: ISO/TR 23381 (mechanical properties and residual stress testing)

- Korean Standards: KS 80550 (indentation tensile property testing)

- ASME Codes: Code Case 2703 (alternative hardness testing)

- Awards: Gold Medal at the Geneva International Exhibition of Inventions



Typical Test Cases

1. Steam Pipeline Comparison (Pre- vs. Post-service)

   - Material: 12Cr1MoV

   - Yield strength error 8%, tensile strength error 6%

2. Storage Tank Strength Test

   - Material: Q235B, average yield strength 261.88 MPa

3. High-Pressure Waste Heat Exchanger Test

   - Material: CrMoV steel, strain hardening index 0.1580.194



Data Support & Technical Services

- Safety Assessment: Covers the entire lifecycle (manufacturing, heat treatment, service, aging).

- Technical Output: Papers, patents, customized fixture design (for complex working conditions).



Contact Information

- Phone/WhatsApp/WeChat: +86-13961802200 (Peggy)

- Email: zhangpeijie@zhanghuayaoji.com

PMT-1000: Safeguarding Energy Equipment Safety with Efficient, Precise On-Site Testing!
